Positive Temperature Coefficient (PTC) Thermistors Automotive Household Air Conditioners Heating Element Essential Efficient

Name: Positive Temperature Coefficient PTC Thermistors Automotive Household Air Conditioners Heating Element Essential Efficient
Brand: linkun
Price: 1 USD

Positive Temperature Coefficient (PTC) Thermistors Automotive Household Air Conditioners Heating Element Essential Efficient Manufactures

Brand Name : linkun

Model Number : Hesting sheet PTC thermistor

Certification : CE / ROHS / UL / TUV / SGS

Place of Origin : Dongguan China

MOQ : Negotiation

Price : Negotiation

Payment Terms : T/T, L/C, Western Union

Supply Ability : 24 million per year

Delivery Time : Negotiation

Packaging Details : Export Package / Negotiation

Application : Heaters for optical communication distributors

Features : No risk of fire

Technology : PTC Thermistor

Package Type : Throught Hole

Type : Thermal Resistor

Certified : RoHS-compatible / UL

Contact Now

Specially designed for high-end car air conditioners, home air conditioners constant temperature heating PTC thermistor positive temperature heating plate ceramic silver electrode heating chip

Features

◆ The temperature pulsation which is observed in the bimetallic thermostat application can be eliminated.
◆ The heater element itself functions as a temperature regualator.
◆ Compact and light design together with simple construction permits easy handing in wining, etc.
◆ Excellent lfe characteristics ensure a longer service life than Nickel-chrome heaters under normal operating conditions.
◆ No risk of fire

Product Description

• Automotive
◆ Cabin heating of electric vehicles
◆ Diesel fuel preheating
◆ Diesel fuel filter heating
◆ Heating of crank case venting system
◆ Windshield washer nozzle heating

• Domestic
◆ Bimetal heaters for door latches of washing machines
◆ Fan heaters
◆ Heaters for optical communication distributors
◆ Insecticide and perfume vaporizers
◆ Oil preheating in oil burners
◆ Thermal actuators for liquid dispensers and thermostats
◆ Heaters for medical appliances

Electrical Specifications

Order Number	Curie Temp.	Surface Temp.	Resistance At25℃	Rated Voltage	Maximum Voltage	Dimensions
Order Number	Tc(℃)	Ts(±10℃)	R25 (Ω)	Vr(V)	Vmax(V)	D/L(mm)	d/W(mm)	T(mm)
MZ2X1Φ190415-2R0□9/40	0	40	2.0	9	18	Φ19.0	Φ4.3	1.5
MZ2P4S1210-9R0□V12/70	40	70	9	12	30	Φ12.0	-	1
MZ2P6S1210-9R0□V12/80	60	80	9	12	30	Φ12.0	-	1
MZ2P8S1210-9R0□V12/95	80	95	9	12	30	Φ12.0	-	1
MZ2P9S0825-360□V24/115	90	115	36	24	30	Φ8.5	-	2.5
MZ2X0S0815-180□V24/120	100	120	18	24	30	Φ8.0	-	1.5
MZ2X1Φ160415□12/120	110	120	2.4	12	24	Φ16.0	Φ4.3	1.5
MZ2X0S0815-100□V24/125	100	125	10	24	30	Φ8.0	-	1.5
MZ2X2S1210-9R0□V12/130	120	130	9	12	30	Φ12.0	-	1
MZ2X3S1215-3R0□V12/140	130	140	3.00	12	14	Φ12.0	-	1.5
MZ2X3S1215-1R5□V12/145	135	145	1.55	13.5	28	Φ12.0	-	1.5
MZ2X5S1216-2R0□V13/160	150	160	2	13.5	28	Φ12.0	-	1.6
MZ2X5S1210-9R0□V12/165	155	165	9	12	30	Φ12.0	-	1
MZ2X8S1210-9R0□V12/185	180	185	9	12	30	Φ12.0	-	1
MZ2X9S0820-100□V18/215	195	215	100	18	36	Φ8.0	-	2
MZ2Y4S1516-4R5□V13/250	240	250	4.5	13.5	24	Φ14.7	-	1.65
MZ2P8S350614-3R2□V12/110	80	110	3.2	12	20	35.0	6.2	1.4
MZ2X3S221225-1R8□V14/145	135	145	1.88	14	18	22.0	12	2.5
MZ2X3S341524-3R1□V24/145	135	145	3.13	24	36	34.0	15	2.4
MZ2X2S350614-3R2□V12/145	120	145	3.2	12	20	35.0	6.2	1.4
MZ2X4S281216-1R6□V14/150	140	150	1.65	13.5	28	28.0	12	1.65
MZ2X4S360820-5R0□V24/150	140	150	5	24	36	36.0	8	2
MZ2X5S300610-4R5□V14/160	150	160	4.5	13.5	24	30.0	5.8	1
MZ2X5S160416-1R5□V12/165	155	165	1.5	12	24	16.5	4.5	1.65
MZ2X6S341524-1R7□V12/170	160	170	1.7	12	24	34.0	15	2.4
MZ2X6S300610-200□V48/170	160	170	20	48	60	30.0	5.8	1
MZ2X7S300610-2R3□V12/180	170	180	2.35	12	24	30.0	5.8	1
MZ2X7S300610-3R0□V12/180	170	180	3	12	24	30.0	5.8	1
MZ2X6S350614-3R2□V12/180	160	180	3.2	12	20	35.0	6.2	1.4
MZ2X8S350614-3R2□V12/200	180	200	3.2	12	20	35.0	6.2	1.4
MZ2Y2S350614-6R4□V12/230	220	230	6.4	12	20	35.0	6.2	1.4

Notes:

1. is the resistance tolerance　M:±20%　X:±25%　N:±30%　S: Special
2. Vr can be selected at 1.5-68V.
3. Ts can be selected at 35-350℃.
4. Other type are available on request.

Order Number	Curie Temp.	Surface Temp.	Resistance At25℃	Rated Voltage	Maximum Voltage	Dimensions
Order Number	Tc(℃)	Ts(±10℃)	R25 (Ω)	Vr(V)	Vmax(V)	D/L(mm)	W(mm)	T(mm)
MZ2P5S1220-122□V230/100	50	100	1200	230	270	Φ11.8	-	2.0
MZ2P9S1220-122□V230/125	90	125	1200	230	270	Φ11.8	-	2.0
MZ2X2S1325-102□V110/135	120	135	1000	110	140	Φ13.0	-	2.5
MZ2X1S0803-422□V230/135	110	135	4200	230	270	Φ8.0	-	3
MZ2X1S1220-122□V230/140	110	140	1200	230	270	Φ11.8	-	2.0
MZ2X3S1220-122□V230/160	130	160	1200	230	270	Φ11.8	-	2.0
MZ2X5S0803-422□V230/170	150	170	4200	230	270	Φ8.0	-	3
MZ2X5S1220-122□V230/180	150	180	1200	230	270	Φ11.8	-	2.0
MZ2X8S0803-422□V230/200	180	200	4200	230	270	Φ8.0	-	3
MZ2Y2S0803-602□V230/235	220	235	6000	230	270	Φ8.0	-	3
MZ2Y3S0803-102□V230/240	230	240	1000	230	270	Φ8.0	-	3
MZ2P5S350620-701□V230/100	50	100	700	230	270	35.0	6.2	2
MZ2P7S350620-701□V230/115	70	115	700	230	270	35.0	6.2	2
MZ2X1S350620-701□V230/145	110	145	700	230	270	35.0	6.2	2
MZ2X3S350620-701□V230/160	130	160	700	230	270	35.0	6.2	2
MZ2X6S241520-302□V220/170	160	170	3000	220	480	24.0	15	2
MZ2X6S241524-152□V360/170	160	170	1500	360	420	24.0	15	2.4
MZ2X5S350620-701□V230/180	150	180	700	230	270	35.0	6.2	2
MZ2X5S281221-302□V400/190	155	190	3000	400	600	28.8	12.4	2.1
MZ2X8S350620-701□V230/205	180	205	700	230	270	35.0	6.2	2
MZ2X9S291021-402□V350/215	190	215	4000	350	800	28.8	9.8	2.1
MZ2X9S393126-151□V600/220	195	220	150	600	750	39.2	30.8	2.6
MZ2Y2S393119-871□V350/240	220	240	875	350	450	39.2	30.8	1.9
MZ2Y2S393125-871□V540/240	220	240	875	540	600	39.2	30.8	2.5
MZ2Y2S350620-102□V230/240	220	240	1000	230	270	35.0	6.2	2
MZ2Y7S350620-132□V230/280	270	280	1300	230	270	35.0	6.2	2

Notes:

1.is the resistance tolerance　M:±20%　X:±25%　N:±30%　S: Special

2.Vr can be selected at 100-1000V.

3.Ts can be selected at 35-350℃.

4.Other type are available on request.
